2.5 Bore x 16 Stroke Hydraulic Cylinder | Chief by Bailey

Description

Introducing the Chief Hydraulic Cylinder 207408, expertly engineered for heavy-duty applications. This high-quality hydraulic cylinder features a robust construction that ensures it can withstand extreme pressure while delivering excellent performance.

• Bore Size: 2.5” diameter – A larger bore allows for increased fluid capacity and force generation.
• Stroke Length: 16” – Ideal for applications requiring significant vertical or horizontal movement.
• Column Load: 14720 lbs – Engineered to handle heavy lifting tasks effortlessly.
• Extended Length: 40” – Perfect for installations that need extended reach.
• Retracted Length: 24” – Compact design allows for easy storage and transport.
• Port Type: SAE 8 ports – Standardized ports for seamless integration with hydraulic systems.
• Weight: 26 lbs – Feasible for installation without requiring excessive manpower.

Constructed with durable materials, the Chief hydraulic cylinder is designed for Maximum reliability and offers corrosion resistance for long-lasting performance. It is a perfect fit for a wide range of applications, from agricultural equipment to construction machinery. Enhance your operations with this hydraulic cylinder’s strength and efficiency.

Applications: Suitable for use in various machines and equipment such as tractors, excavators, and forklifts.

Care Instructions: Always inspect the hydraulic cylinder before each use. Ensure proper hydraulic fluid levels and check for leaks to maintain optimal performance.

Ready to elevate your equipment’s capabilities? Don’t miss out on the Chief Hydraulic Cylinder 207408.

If you need assistance choosing the proper hydraulic cylinder or have any questions, feel free to contact us at (800) 823-4937.
