FallTech 8242 6′ WeldTech Single-Leg Snap-Hook Lanyard

Description

FallTech WeldTech Welding Lanyards

FallTech 8242 and C8242 6 ft WeldTech Single-Leg Energy-Absorbing Lanyard with Steel Snap Hooks

The FallTech WeldTech 8242 is a 6 ft single-leg energy-absorbing lanyard built for welding and hot-work. Kevlar leg webbing and a Nomex-covered Softpack energy absorber resist slag, spatter, and burns that would damage standard polyester. In a fall, the Softpack absorber deploys to keep arrest forces within safe limits. Choose your certification at checkout: the 8242 is certified to ANSI Z359.13-2013 for US jobsites, and the C8242 to CSA Z259.11-17 for Canada.

Alloy steel snap hooks connect at the harness and anchorage ends, each self-closing and self-locking with 3,600 lb gate strength. The ANSI model is rated for a worker up to 310 lb combined weight and the CSA model for a worker from 120 to 350 lb combined weight, with a 6 ft maximum free fall. Certified to ANSI Z359.13-2013 (model 8242) or CSA Z259.11-17 (model C8242), aligning with OSHA 1926.502 and 1910.66.

310/350 lbsCapacity ANSI/CSA6 ftLanyard Length6 ftMax Free Fall4.5 ftMax Absorber Deployment18 ftMin Fall Clearance5,000 lbsWebbing Static StrengthKevlarLeg WebbingANSI / CSAZ359.13 or Z259.11

Who Needs This Product

This product is a welding-grade energy-absorbing lanyard (EAL), a fall-arrest connecting device built for hot-work. Welders, ironworkers, and fabricators use the WeldTech to tie off where sparks and spatter would burn through a standard lanyard. Pick the ANSI version (8242) for the US or the CSA version (C8242) for Canada. You still need a certified full-body harness and a rated anchorage to complete the personal fall-arrest system.

Features

Softpack energy absorber

A compact Softpack energy absorber with a Nomex cover deploys in a fall to keep arrest forces within limits.

Nomex and Kevlar construction

Kevlar leg webbing and a Nomex absorber cover resist slag, spatter, and burns in hot-work welding.

Spatter and burn resistant

Built for welding and hot-work where standard polyester webbing would be damaged.

Alloy steel snap hooks

Self-closing, self-locking alloy steel snap hooks connect at both the harness and anchorage ends.

Alloy steel connectors

Self-closing, self-locking alloy steel hooks with 3,600 lb gate strength.

Dual certified ANSI and CSA

Available ANSI Z359.13-2013 or CSA Z259.11-17, one lanyard for both sides of the border.

⚠

Confirm your fall clearance before every use. This lanyard allows up to 6 ft of free fall and the absorber can deploy up to 4.5 ft, so the minimum required fall clearance is about 18 ft below the work surface in an overhead configuration. Anchor overhead where possible, connect only to a certified full-body harness dorsal D-ring, and run the Fall Protection Calculator below before you rig.

Compliance Standards

ANSI Z359.13-2013

American National Standard for personal energy absorbers and lanyards (model 8242).

CSA Z259.11-17

Canadian standard for personal energy absorbers and lanyards (model C8242). Certified by the IAS-accredited FallTech test lab, TL-594.

OSHA 29 CFR 1926.502

Federal construction fall protection requirements.

OSHA 29 CFR 1910.66

General industry personal fall protection requirements.

Typical Applications

General constructionEveryday overhead tie-off.MaintenanceRecurring work at height with a rated anchor.Welding and hot-workSpatter and burn resistant tie-off.Oil and gasProduction and service tie-off.General industryFall arrest under OSHA 1910 and provincial rules.FabricationShop and field welding at height.

How to Use the 8242

Follow the FallTech instruction manual. The sequence below is an overview only.

1. Inspect. Check the webbing, stitching, energy absorber, and all connectors before each use.
2. Anchor. Connect one snap hook to a rated anchorage, positioned overhead where possible to limit free fall.
3. Connect to the harness. Attach the harness connector to the dorsal D-ring of a certified full-body harness.
4. Confirm the connections. Verify every hook gate is fully closed and locked.
5. Verify clearance. Confirm fall clearance and swing-fall below the work surface, and run the calculator below.

Inspection and Retirement

Inspect before each use, with a documented competent-person inspection at intervals set by your site conditions and at least annually. Pull the lanyard from service for any of the conditions below.

• Webbing: cuts, fraying, abrasion, burns, or chemical damage.
• Energy absorber: any sign of deployment, or a torn or damaged cover.
• Stitching: pulled, cut, or broken threads.
• Hooks: deformation, corrosion, or gates that fail to close and lock.
• Labels: illegible or missing markings.

Retire the lanyard immediately after any fall-arrest event, or if any inspection point fails. Destroy retired equipment so it cannot return to service.

Fall ProtectionDistributors, LLC Free Tool · No Signup · OSHA 1926.502 Free Interactive Tool Fall Protection Calculator Pick your system. Run the math. Generate a plan. 1Pick Your SystemDetermine fall restraint vs. fall arrest based on your work surface, edge access, and clearance. 2Run the MathCalculate exact fall clearance required below the work surface for your lanyard or SRL setup. 3Generate a PlanGet a printable OSHA-compliant Fall Protection Plan structured around 29 CFR 1926.502(k). Run the Numbers and Stay Safe Launch the Calculator ›

Technical Specifications

SKU	8242 (ANSI Z359.13) or C8242 (CSA Z259.11)
Manufacturer Part Number	8242 (ANSI) / C8242 (CSA)
Type	Single-leg welding energy-absorbing lanyard, 6 ft
Webbing	1 in Kevlar leg webbing with Nomex absorber cover, 5,000 lb minimum static strength
Energy absorber	Softpack energy absorber with Nomex cover; Kevlar leg webbing for spatter and burn resistance
Harness end	Alloy steel snap hook
Anchorage end	Alloy steel snap hook
Connector strength	5,000 lb minimum static, 3,600 lb gate strength
Capacity	310 lb maximum combined weight (ANSI model); 120 to 350 lb combined weight (CSA model)
Maximum free fall	6 ft (1.8 m)
Maximum absorber deployment	4.5 ft (1.4 m)
Minimum required fall clearance	18 ft (5.5 m) overhead configuration, worst case
Certification options	8242 = ANSI Z359.13-2013 (US); C8242 = CSA Z259.11-17 (Canada). Select at checkout.
Standards	ANSI Z359.13-2013; CSA Z259.11-17; OSHA 1926.502 and 1910.66
Warranty	FallTech 2-year limited warranty against defects in materials and workmanship
UPC	848013042583 (8242) / 848013040008 (C8242)

Frequently Asked Questions

Which certification options are available?Two versions on one page: the 8242 is certified to ANSI Z359.13-2013 for US jobsites, and the C8242 to CSA Z259.11-17 for Canada. Select your standard at checkout; both are the same physical lanyard.What is the rated capacity?One worker per lanyard. The ANSI model is rated to 310 lb maximum combined weight of the user, tools, and clothing per the FallTech ANSI manual, and the CSA model is rated for 120 to 350 lb combined weight per the FallTech CSA manual.How much fall clearance does it need?Plan on about 18 ft of clearance below the work surface in an overhead configuration, based on a 6 ft free fall plus up to 4.5 ft of absorber deployment. Use the Fall Protection Calculator to confirm the exact value for your worker weight and anchor position. The FallTech CSA manual specification table lists an average arrest force (FAVG) of 3.7 kN (831.8 lb) for this lanyard family.What connects at each end?An alloy steel snap hook at both the harness and anchorage ends, each with self-closing, self-locking gates rated to 3,600 lb.What makes WeldTech different from a standard lanyard?WeldTech uses Kevlar leg webbing and a Nomex-covered Softpack absorber that resist slag, spatter, and burns from welding and hot-work, where standard polyester webbing would be damaged.Do I need a harness with this lanyard?Yes. An energy-absorbing lanyard is a connecting device only. You need a certified full-body harness and a rated anchorage to complete the personal fall-arrest system.What is the difference between fall arrest and fall restraint?Fall arrest catches a worker after a fall happens; fall restraint prevents the worker from reaching the fall hazard in the first place. Use the Fall Protection Calculator below to size the right system for your job.

FallTech 8242 and C8242 Submittals and Documentation

8242 ANSI Instruction Manual (PDF)Use, limitations, capacity, fall clearance, and inspection. 8242 CSA Instruction Manual (PDF)Bilingual EN/FR use, limitations, and inspection. 8242 ANSI Declaration of Conformity (PDF)Certification to ANSI Z359.13-2013 from the FallTech test lab. 8242 CSA Declaration of Conformity (PDF)Certification to CSA Z259.11-17 with the IAS-accredited FallTech lab. 8242 Spec Sheet (PDF)One-page specifications and compliance summary. 8242 Canada Catalogue Supplement (PDF)FallTech Canadian product line reference.
