Rotary Air/Hydraulic Scissor Lift Tables

Sale!
Rotary Air/Hydraulic Scissor Lift Tables

Rotary Air/Hydraulic Scissor Lift Tables

Original price was: $3,462.44.Current price is: $2,669.50.

57 in stock

SKU: AHLT-2448-3-43 Category:

Description

Utilize the convenience of factory air to power these Vestil Rotary Air/Hydraulic Scissor Lift Tables

Simply connect to an 80 CFM & 80 PSI (minimum) air supply (minimum 3/4″ supply recommended) through a filter, regulator, lubricator and you now have a lift table suitable for a wide range of applications and operating environments. Features pneumatic upper travel limit switch, safety toe guards, cylinder with internal safety velocity fuse, two button hand control, and life-time lubricated sleeve bearings.

Rotary Air Hydraulic Scissor Lift Tables
Model Image PDF’s Platform Size (WxL) Lowered Height Raised
Height		 Capacity
(lbs)		 Weight (lbs)
AHLT-2448-3-43 24″x48″ 7″ 43″ 3,000 689
AHLT-3060-3-43 30″x60″ 7″ 43″ 3,000 787
AHLT-4048-3-43 40″x48″ 7″ 43″ 3,000 769
AHLT-4848-3-43 48″x48″ 7″ 43″ 3,000 780
AHLT-4872-3-43 48″x72″ 7″ 43″ 3,000 937

KEY:= Approval Drawing –= Warranty –= Testing Certificate
