Wall Toggle Switch- Deco- SPST- 120/277 VAC- 15 Amp- White

Description

start of prefixes

end of prefixes

start of suffixes

Eaton, Model 7501W Decora Quite White S-P Rocker SwitchPRODUCT OVERVIEWUltrasonic welding and integrated construction of the strap and body. Backwire clamps on the side terminals for installation of 12 and 14 wire. Thermoplastic rocker, top and backbody are virtually unbreakable. Screws accept slotted, Phillips and Robertson head tools for installation in both the U.S. and Canada. Longer, wider strap provides 40 percent more contact area to wall board. Virtually eliminates floating installations. Built-in wire stripper for 12 and 14 wire. Stippled ground screw standard. 15 amp, 120/277 volt AC rating for fluorescent lighting fixtures typical in commercial applications. Push in terminals accept 14 solid wire only. Temperature rating of -20 to 60 degrees C. Meets flammability requirements per UL 94, 6504, V2 rated, VO rated. UL and cUL Listed, Meets all UL20 requirements
